X-ray Attenuation Modelling

X-ray attenuation modelling is a crucial aspect of medical imaging, materials science, and industrial radiography. It describes the reduction in X-ray intensity as the beam passes through a material, governed by fundamental interactions such as photoelectric absorption, Compton scattering, and, at higher energies, pair production. Understanding and accurately modelling X-ray attenuation is essential for optimising imaging techniques, improving radiation safety, and enhancing material characterisation.

Fundamentals of X-ray Attenuation

The attenuation of X-rays is mathematically described by the Beer-Lambert law:

I = I₀e^−μx

Where I is the transmitted intensity, I₀ is the incident intensity, μ is the linear attenuation coefficient, and x is the thickness of the material. The attenuation coefficient, μ, depends on the material’s density and atomic composition, as well as the X-ray photon energy.

Two primary mechanisms contribute to X-ray attenuation in most diagnostic and industrial applications:

Photoelectric Absorption: This process occurs when an X-ray photon transfers its energy to an inner-shell electron, ejecting it from the atom. The probability of photoelectric absorption increases with the atomic number (Z) of the material, following an approximate relationship of Z³ to Z⁴. This mechanism is particularly important at lower X-ray energies and is the dominant factor in high-Z elements such as lead.

Compton Scattering: In this interaction, an X-ray photon collides with an outer-shell electron, transferring part of its energy and changing direction. The scattered photon has lower energy, contributing to image noise in medical imaging. Compton scattering dominates at intermediate energies and is significant in materials with low to moderate atomic numbers.

At very high photon energies (above 1.022 MeV), pair production can occur, where the photon transforms into an electron-positron pair, though this is rare in diagnostic imaging.

Modelling Techniques

Accurate modelling of X-ray attenuation requires detailed knowledge of material properties and photon interactions. Several approaches exist:

Empirical Models: These use experimental data to determine attenuation coefficients for different materials. Databases such as the NIST XCOM database provide attenuation coefficients for a wide range of elements and compounds.

Monte Carlo Simulations: These statistical methods model individual photon interactions to provide highly accurate attenuation predictions. They are computationally intensive but essential for simulating complex geometries in radiotherapy and industrial applications.

Analytical Models: These involve mathematical approximations to estimate attenuation based on material composition and photon energy. They are useful for rapid calculations but may lack precision in heterogeneous materials.

Applications and Challenges

X-ray attenuation modelling plays a key role in computed tomography (CT), where accurate attenuation coefficients enable tissue differentiation. It is also essential in non-destructive testing, security screening, and radiation shielding design. The main challenge lies in modelling heterogeneous structures, where attenuation varies spatially. Advances in AI-driven modelling and improved Monte Carlo techniques continue to enhance accuracy and efficiency in this field.
