Medical optical imaging encompasses diverse techniques leveraging light to visualise internal body structures. It plays a pivotal role in diagnostics and treatment in modern medicine. These methods offer unique insights into the body’s internal workings, aiding significantly in clinical procedures.
One critical application of optical imaging is robotic surgery through endoscopy. This technique employs a flexible tube with a light and camera attached, allowing surgeons to view otherwise inaccessible parts of the patient’s body. Such visual access is crucial during robotic surgeries, where precision and minimal invasiveness are paramount. The integration of endoscopy in robotic systems enhances the surgeon’s ability to navigate complex procedures with increased accuracy.
Optical Coherence Tomography (OCT) is another vital optical imaging technique extensively used in ophthalmology and cardiology. OCT provides high-resolution, cross-sectional images of the retina, helping diagnose and monitor eye diseases. Cardiologists utilise OCT to obtain detailed images of the coronary arteries, assisting in the diagnosis and treatment planning of coronary artery disease. The ability to see beneath the surface of tissues adds a layer of detail that traditional imaging techniques cannot provide.
Photoacoustic imaging combines laser optics and ultrasonic waves to create images of the body’s internal structures. In this method, laser pulses targeted at tissues cause slight heating, expanding the tissues and generating ultrasound waves. These waves are then captured to produce images, which are particularly useful in detecting changes in blood vessel growth within tumours or identifying melanomas on the skin.
Diffuse Optical Tomography (DOT) provides insights into brain activity by utilising near-infrared light. This light penetrates the skull and is scattered by the brain tissue. By analysing the light scattering, researchers can infer brain activity based on physiological changes, such as neuron swelling during neural signal transmission.
Raman scattering is a sophisticated technique where laser light interacts with molecular vibrations, providing detailed information about a material’s chemical composition. This method is crucial in studying biochemical changes in cells and tissues and is often employed in cancer diagnostics to identify abnormal cellular changes.
Super-resolution microscopy, such as Photoactivated Localisation Microscopy (PALM), pushes the boundaries of cellular imaging. PALM uses fluorescent markers to achieve extremely high-resolution images of individual cells, revealing details at the molecular level that are invisible under conventional microscopes.
Finally, an experimental approach, terahertz tomography, uses terahertz radiation—electromagnetic waves situated between microwaves and infrared light—to capture sectional images of the body. Still, in the developmental phase, this technique promises to offer new perspectives on the body’s internal structures, potentially revealing features that are not detectable with existing imaging modalities.
These optical imaging techniques represent the cutting edge of medical science, combining physics, biology, and advanced technology to improve diagnostic accuracy and treatment efficacy in medicine.
